Name: 6HTAA65G22 SDEC Diesel Generator 150kVA Open Type Genset
Brand: DELLENT
Price: 1 USD

Add to Cart

6HTAA6.5-G22 SDEC Diesel Engine 150kVA Open Type Genset

Ⅰ. PRODUCT DESCRIPTION

150kVA Standby Power SDEC Genset Soundproof Engine By 6 Cylinder In Line.Dellent Power supply the standby power 150kVA water cooled diesel generator with SDEC brand diesel engine model6HTAA6.5-G22. The water cooled diesel generator with rated output 165kVA /132kW, standby power150kVA /120kW.

1. Diesel generators are strong-built, ideal for emergency back-up,job sites and industrial appplications.

2. Powered by reliable air/water cooled diesel generators sets, industrial grade, great fuel efficiency, less maintenance, long operating life.

3. Strong technology and high-quality personnel, continuous innovation and perfect management.

150kVA Diesel Generator Powered by SDEC Diesel Engine:

Specification of the Diesel Engine:

Engine Manufacturer		Shanghai Diesel Engine Co., Ltd.
Engine Brand		SDEC
Engine Model		6HTAA6.5-G22
No. of Cylinder		6 Cylinder in line
Aspiration		Turbocharged and Air to Air Aftercooled
Governor		Electric
Engine Max. Output Power	kW	155
Displacement	L	6.500
Starting Voltage	V	24
Bore	mm	105
Stroke	mm	124
Lubrication Oil Capacity	L	15-17.5
Compression Ratio		16 : 1
Intake Air Flow	M3/Min	N.A
Fuel Consumption at 100% Load	L	33.1

Specification of Automatic Control Panel:

Controller Brand	Deepsea
Controller Model	DSE6120
Breaker Brand	Delixi
Breaker Capacity	A	250
Battery Charger	Smartgen Model BAC06A
Emergency Stop Button	Supply
Automatic Mains Fail (AMF)	Supply
Fuel Level	Supply
Automatic Transfer Switch	ATS as optional part
Mains Monitor	Supply with DELLENT Function
The control panel supply the full protection with alarm and shutdown of the diesel generator include Start-up fault (generator set shutdown), High coolant temperature (alarm and generator set shutdown), Low oil pressure (alarm and generator set shutdown), Low fuel level (alarm), Low cooling fluid level alarm (as optional), Overload (alarm and generator set shutdown), Battery voltage high (alarm).


Optional controller: Each model of Deepsea, Smartgen, ComAp brand controller.

Ⅲ. QUALIFICATION CENTIFICATE:

Ⅳ. FACTORY INTERIOR:
