Product Introduce:Dellent Power Doosan Series generator powered by the original
Doosan engine.As an authorized Doosan generator dealer, we offer a wide range of
models to suit any power needs and budget. From compact and
portable generators to heavy-duty industrial generators, we have
the expertise and resources to help you find the perfect generator
for your needs.
At our Doosan generator dealership, we understand the importance of
quality and reliability when it comes to power generation. That's
why we only offer the best generators from Doosan, a leading
manufacturer of power equipme
Product parameters:
Specification of 200kVA Emergency Standby Generator:
| Model | DE-DS200 | | Max. Power | kVA | 220 | | kW | 176 | | Rate Power | kVA | 200 | | kW | 160 | | Frequency | Hz | 50 | | Rate Voltage | V | 400/230 | | Rate Current | A | 288.7 | | Fuel Tank Capacity | L | 350L | | Dimension For Open-type Genset | mm | 2590 X 950 X 1600 | | Weight For Open-type Genset | kg | 2000 | | Dimension For Soundproof Genset | mm | 3500X 1126 X 1700 | | Weight For Soundproof Generator | kg | 2690 | | Noise Level for Soundproof Generator at 7M | dBA | 78 | | Battery | Two of 120Ah Free Maintenance Battery
|
|
|
Specification of Doosan Diesel Engine P086TI:
| Engine Manufacturer | Doosan Infracore | | Engine Brand | Doosan | | Engine Model | P086TI | | No. of Cylinder | 6 Cylinder in line | | Aspiration | Turbocarged | | Governor | Electric | | Engine Max. Output Power | kW | 199 | | Displacement | L | 8.1 | | Compression Ratio | 16.4 : 1 | | Starting Voltage | V | 24 | | Bore | mm | 111 | | Stroke | mm | 139 | | Lubrication Oil Capacity | L | 19 | | Intake Air Flow | M3/Min | 13.9 | | Fuel Consumption at 100% Load | L/H | 44.7 |
|
Specification of Control Panel :
Specification of Control Panel for 200kVA Emergency Standby
Generator:
| Controller Brand | ComAp |
| Breaker Brand | Delixi |
| Breaker Capacity (A) | 400 |
| Battery Charger | Smartgen |
| Emergency Stop Button | Supply |
| Automatic Mains Fail (AMF) | Supply |
| Fuel Level | Supply |
| Automatic Transfer Switch | ATS as optional part |
| The control panel supply the full protection with alarm and
shutdown of the diesel generator include Start-up fault (generator
set shutdown), High coolant temperature (alarm and generator set
shutdown), Low oil pressure (alarm and generator set shutdown), Low
fuel level (alarm), Low cooling fluid level alarm (as optional),
Overload (alarm and generator set shutdown), Battery voltage high
(alarm). |
|
|
| Optional controller: Each model of Deepsea, Smartgen, ComAp brand
controller. |
Ⅱ. Why Choose Us:
Ⅲ. QUALIFICATION CENTIFICATE:
Ⅳ. FACTORY INTERIOR:
FAQ
Q: What's your delivery time?
A: Standard product 20 days - 30 days.
Q: Can we add our logo to products?
A: Yes, there are several ways to do this. We can put the label of
your logo on the products or make the silk print of your logo on
the products. It is free.
Q: Can we customize the product?
A: We have a very experienced technical team, we can customize any
product according to your requirements, such as synchronization
system, wet exhaust system, ultra-silent system
